CONNECTING ROD 99-03 RM125, PSYCHIC MX-09057 REPAIR KIT
4.1 Trustpilot 99.9% positive on eBay
UK delivery £4.99, free over £60 2–4 business days
Spread the cost with
18+, T&Cs apply
CONNECTING ROD REBUILD KIT for Suzuki RM125 1999-2003. PSYCHIC MX-09057. Heavy-duty OE replacement connecting rods. Certified Chrome alloy steel provides superior strength. Crankpins are manufactured from hot-rolled ASTM steel and case hardened. Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity. Thrust washers are manufactured from bronze phosphor and are silver coated. Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers. Fully Compatible with after market and OE crankshafts. Material SNCM220. Centre to Centre: 102mm. Small End Bearing: 15x19x20mm. Small End Bore: 19mm. Small End Width: 17.90mm. Big End Bearing: 22x28x16mm. Big End Bore: 28.00mm. Big End Width: 15.90mm. Big End Pin: 22mm Diameter, 52.90mm Length. Washer Thickness: 22x42X1mm.
- SKU
- 56-117.DR
- Brand
- Psychic
- Availability
- In Stock (2)
Fitments (5)
| Make | Model | Year |
|---|---|---|
| SUZUKI | RM 125 | 1999 |
| SUZUKI | RM 125 | 2000 |
| SUZUKI | RM 125 | 2001 |
| SUZUKI | RM 125 | 2002 |
| SUZUKI | RM 125 | 2003 |
- General Product Group
- Crankshafts & Parts
- General Product Type
- Connecting Rod
- Variant Id
- 249990
FULL DESCRIPTION
Psychic MX-09057 Connecting Rod Rebuild Kit
This is a heavy-duty OE replacement connecting rod rebuild kit designed for high performance and longevity. Crafted from certified chrome alloy steel, it provides superior strength and durability.
Key Features:
- Material: Certified chrome alloy steel (SNCM220) for exceptional strength.
- Crankpins: Manufactured from hot-rolled ASTM steel and case-hardened for increased wear resistance.
- Bearing Design: Utilizes the latest in caged needle roller bearing technology for high RPM longevity.
- Thrust Washers: Made from silver-coated phosphor bronze for optimal performance.
- Complete Kit: Includes the rod, crankpin, crankpin bearing, top end bearing, and thrust washers where applicable.
- Compatibility: Fully compatible with both aftermarket and OE crankshafts.
Specifications:
- Centre to Centre: 102 mm
- Small End Bearing: 15x19x20 mm
- Small End Bore Diameter: 19 mm
- Small End Width: 17.90 mm
- Big End Bearing: 22x28x16 mm
- Big End Bore Diameter: 28.00 mm
- Big End Width: 15.90 mm
- Big End Pin Diameter: 22 mm
- Big End Pin Length: 52.90 mm
- Washer Thickness: 22x42x1 mm
