High-quality connecting rod kit designed for Suzuki RM80 models. Made from hot-rolled ASTM 4115 steel and case-hardened to 58–62 Rc for superior strength. Features advanced design with strategically located side scalloping and vent slots to reduce high RPM bearing race distortion. Double-forged for improved grain flow and dimensional consistency. Shot-peened and double-honed for added strength under heavy loads. Double-drilled small ends enhance lubrication and cooling of the wrist pin bearing. Silver-coated thrust washers and crank pin bearings for enhanced lubricity. Includes rod, crank pin, crank pin bearing, top end bearing, and thrust washers. Specifications: Big End Bearing 20x26x14 mm, Big End Bore 26.00 mm, Big End Width 14 mm, Center to Center 93.50 mm, Pin Diameter 20.00 mm, Pin Length 44.70 mm, Small End Bore 18.00 mm. Manufacturer: Hot Rods. Part Number: 56-141.HR.
- SKU
- 56-141.HR
- Brand
- Hot Rods
- Availability
- In Stock (1)
Fitments (12)
| Make | Model | Year |
|---|---|---|
| SUZUKI | RM 80 | 1990 |
| SUZUKI | RM 80 | 1991 |
| SUZUKI | RM 80 | 1992 |
| SUZUKI | RM 80 | 1993 |
| SUZUKI | RM 80 | 1994 |
| SUZUKI | RM 80 | 1995 |
| SUZUKI | RM 80 | 1996 |
| SUZUKI | RM 80 | 1997 |
| SUZUKI | RM 80 | 1998 |
| SUZUKI | RM 80 | 1999 |
| SUZUKI | RM 80 | 2000 |
| SUZUKI | RM 80 | 2001 |
- General Product Group
- Crankshafts & Parts
- General Product Type
- Connecting Rod
- Variant Id
- 250053
FULL DESCRIPTION
Hot Rods Connecting Rod Kit for Suzuki RM80
Engineered for peak performance and longevity, this high-quality connecting rod kit is specifically designed for Suzuki RM80 motorcycles. Manufactured to strict standards, it ensures optimal engine function and provides the reliability needed for any rebuild project.
Key Features:
- Constructed from hot-rolled ASTM 4115 steel for exceptional strength.
- Case-hardened to 58-62 Rc for enhanced durability under stress.
- Advanced design includes strategically placed side scalloping and vent slots to mitigate high RPM bearing race distortion.
- Double-forged process improves grain flow and ensures consistent dimensions.
- Shot-peened and double-honed surfaces add strength for heavy load conditions.
- Double-drilled small ends facilitate superior lubrication and cooling for the wrist pin bearing.
- Features silver-coated thrust washers and crank pin bearings for improved lubricity.
- This comprehensive kit includes the rod, crank pin, crank pin bearing, top end bearing, and thrust washers, offering a complete solution for engine rebuilds.
Specifications:
- Big End Bearing: 20x26x14 mm
- Big End Bore: 26.00 mm
- Big End Width: 14 mm
- Center to Center Length: 93.50 mm
- Pin Diameter: 20.00 mm
- Pin Length: 44.70 mm
- Small End Bore: 18.00 mm
