PISTON KIT SMR560 KTM HC.100, FORGED 8704DB WOSSNER

£203.33Only 1 left

4.4 Trustpilot 99.9% positive on eBay

Free UK delivery 2–4 business days

Spread the cost with Klarna 18+, T&Cs apply

1

Wossner forged piston kit with a 100.01mm bore and 99.96mm diameter, designed for KTM SMR560 models. This high-compression piston (12.00:1) enhances performance and durability. Manufactured in Germany, it ensures optimal heat transfer to cylinder walls. Its elliptical design provides a uniform bearing surface under heat expansion, reducing localized pressure and evenly distributing thrust loads to prevent piston collapse. Forged construction for superior strength. Optimized heat transfer for efficient combustion. Elliptical design for uniform load distribution. Bore: 100.01mm. Diameter: 99.96mm. Display (cm³): 600. Stroke (mm): 72.00. Clearance (mm): 0.05. Wossner Compression Ratio: 12.00:1. OEM Compression Ratio: 11.00:1. Dome Volume (cm³): +5.20. Compression Height (mm): 23.40. Cross-Reference OEM Part Numbers: Wossner Piston KTM SMR560 (PN# 8704DB). Lock P/N: CW20. Pin P/N: WP038. Ring Set P/N: 1000ADS-2.

Specifications
SKU
56-W247.B
Brand
Wossner
Availability
In Stock (1)

Fitments (4)

MakeModelYear
KTM560 SM R2006
KTM560 SM R2007
KTM560 SM R2008
KTM560 SM R2009
General Product Group
Engine
General Product Type
Pistons & Kits
General Size
100mm
Variant Id
255195
Delivery2–4 business days
14-Day ReturnsHassle-free
Easy CheckoutCard friendly
Product details

FULL DESCRIPTION

Wossner Forged Piston Kit for KTM SMR560

Elevate the performance and durability of your KTM SMR560 with this high-quality Wossner forged piston kit. Engineered for demanding riders, this piston delivers enhanced power and reliability.

Key Features

  • Forged Construction: Provides superior strength and resilience compared to cast pistons, ensuring longevity under high stress.
  • High Compression Ratio: Features a 12.00:1 compression ratio (compared to OEM 11.00:1), designed to significantly increase engine power and responsiveness.
  • Optimized Heat Transfer: Manufactured in Germany with precision, this piston promotes efficient heat transfer to the cylinder walls, contributing to optimal combustion and engine longevity.
  • Elliptical Design: The unique elliptical profile ensures a uniform bearing surface even under extreme operating temperatures. This reduces localized pressure points and evenly distributes thrust loads, preventing piston collapse and extending component life.
  • Precision Engineering: Meticulously crafted in Germany to meet exacting standards.

Specifications

  • Bore Size: 100.01mm
  • Piston Diameter: 99.96mm
  • Displacement: 600 cm³
  • Stroke: 72.00mm
  • Piston Clearance: 0.05mm
  • Wossner Compression Ratio: 12.00:1
  • OEM Compression Ratio: 11.00:1
  • Dome Volume: +5.20 cm³
  • Compression Height: 23.40mm

Kit Components

  • Wossner Piston (Part Number: 8704DB)
  • Lock Rings (Part Number: CW20)
  • Piston Pin (Part Number: WP038)
  • Ring Set (Part Number: 1000ADS-2)
