PISTON KIT LTR450 HC 95.50 B, WOSSNER 8699DB 13.3:1 COMP, SUZUKI
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner 8699DB forged piston kit for Suzuki LTR450. High-compression piston with a 95.51mm bore and 13.3:1 compression ratio. Features include improved heat management and durability through forged construction and an elliptical design for even pressure distribution. Specifications: Bore 95.51 mm, Actual Bore Diameter 95.46 mm, Display 450 cm³, Hub Stroke 62.80 mm, Clearance 0.05 mm, Compression Height 24.50 mm, Dome Volume +2.30 cm³, Wossner Compression Ratio 13.30:1, OEM Compression Ratio 11.70:1. Cross-reference OEM Part Numbers: Piston 8699DB, Lock CW19, Pin WP037, Ring Set 955XSY, Rod P4011, Part No. 56-W4912.WO.B. Manufactured in Germany.
- SKU
- 56-W4912.WO.B
- Brand
- Wossner
- Availability
- In Stock (2)
Fitments (4)
| Make | Model | Year |
|---|---|---|
| SUZUKI | LTR 450 | 2006 |
| SUZUKI | LTR 450 | 2007 |
| SUZUKI | LTR 450 | 2008 |
| SUZUKI | LTR 450 | 2009 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 95.5mm
- Variant Id
- 256357
FULL DESCRIPTION
Wossner 8699DB Forged Piston Kit - High Compression for Suzuki LTR450
Enhance the performance and durability of your Suzuki LTR450 with the Wossner 8699DB forged piston kit. Engineered in Germany, this high-compression piston is designed for superior heat management and strength, ensuring reliable operation under demanding conditions.
Key Features:
- Forged construction for exceptional strength and longevity.
- High-compression design delivers increased power output.
- Optimized for efficient heat transfer from the combustion chamber to the cylinder walls.
- Elliptical piston design ensures even load distribution, preventing collapse under thermal expansion.
- Reduces the risk of localized pressure points and piston failure.
- Precision manufactured in Germany for uncompromising quality.
Specifications:
- Bore: 95.51 mm
- Actual Bore Diameter: 95.46 mm
- Engine Displacement: 450 cm³
- Stroke: 62.80 mm
- Piston Clearance: 0.05 mm
- Compression Height: 24.50 mm
- Dome Volume: +2.30 cm³
- Wossner Compression Ratio: 13.30:1
- Original Equipment Manufacturer (OEM) Compression Ratio: 11.70:1
Kit Components:
- Piston (Part No. 8699DB)
- Lock Rings (Part No. CW19)
- Piston Pin (Part No. WP037)
- Ring Set (Part No. 955XSY)
- Connecting Rod (Part No. P4011)
