PISTON KIT KXF RMZ 250 77.00 C, FORGED WOSSNER 8582DC

£168.44Only 1 left

4.4 Trustpilot 99.9% positive on eBay

Free UK delivery 2–4 business days

Spread the cost with Klarna 18+, T&Cs apply

1

Wossner 77.02mm forged piston kit engineered for strength and durability. Designed for optimal heat transfer, it ensures efficient cooling of the combustion chamber. The elliptical design provides a uniform bearing surface, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany for precision and reliability. Features include forged construction for enhanced strength and longevity, optimized heat transfer for improved engine performance, and an elliptical design that prevents piston collapse and ensures even load distribution. Specifications: Bore Size: 77.02mm, Actual Bore Diameter: 76.98mm, Displacement: 249 cm³, Stroke: 53.60mm, Clearance: 0.04mm, Wossner Compression Ratio: 12.10:1, OEM Compression Ratio: 12.60:1, Dome Volume: -5.90 cm³, Compression Height: 19.60mm, Gasket Part Number: D4013, Lock Part Number: CW16, Pin Part Number: WP059, Ring Set Part Number: 770XAS, Rod Part Number: P4002. Cross-Reference OEM Part Numbers: Part No: 56-W4842.C.WO, Wossner Part No: 8582DC.

Specifications
SKU
56-W4842.C.WO
Brand
Wossner
Availability
In Stock (1)

Fitments (12)

MakeModelYear
KAWASAKIKX 250F2004
KAWASAKIKX 250F2005
KAWASAKIKX 250F2006
KAWASAKIKX 250F2007
KAWASAKIKX 250F2008
KAWASAKIKX 250F2009
SUZUKIRM-Z 2502004
SUZUKIRM-Z 2502005
SUZUKIRM-Z 2502006
SUZUKIRM-Z 2502007
SUZUKIRM-Z 2502008
SUZUKIRM-Z 2502009
General Product Group
Engine
General Product Type
Pistons & Kits
General Size
77mm
Variant Id
256244
Delivery2–4 business days
14-Day ReturnsHassle-free
Easy CheckoutCard friendly
Product details

FULL DESCRIPTION

Wossner 77.02mm Forged Piston Kit

Enhance your engine's performance and durability with this Wossner 77.02mm forged piston kit. Engineered in Germany, this high-quality piston is designed for optimal strength and longevity.

The forged construction provides superior resilience compared to cast pistons, ensuring it can withstand the demands of high-performance applications. Its specialized elliptical design offers a uniform bearing surface, which effectively reduces localized pressure and distributes thrust loads evenly. This intelligent design prevents piston collapse and contributes to a smoother engine operation.

This piston kit is engineered for optimal heat transfer, which is crucial for efficient cooling of the combustion chamber. This contributes to improved engine performance and helps maintain consistent operating temperatures.

Key Features

  • Forged construction for exceptional strength and extended lifespan.
  • Optimized heat transfer capabilities for improved engine cooling and performance.
  • Unique elliptical design prevents piston collapse and ensures even load distribution across the cylinder wall.
  • Precision manufactured in Germany, guaranteeing high-quality standards and reliability.

Specifications

  • Bore Size: 77.02mm
  • Actual Bore Diameter: 76.98mm
  • Displacement: 249 cm³
  • Stroke: 53.60mm
  • Clearance: 0.04mm
  • Wossner Compression Ratio: 12.10:1
  • OEM Compression Ratio: 12.60:1
  • Dome Volume: -5.90 cm³
  • Compression Height: 19.60mm
  • Gasket Part Number: D4013
  • Lock Part Number: CW16
  • Pin Part Number: WP059
  • Ring Set Part Number: 770XAS
  • Rod Part Number: P4002
