PISTON KIT HC HUSKY610 98.00, WOSSNER 8568DC HUSQVARNA
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner forged piston kit with HC (high compression) design. Engineered for superior strength and optimal heat transfer from the combustion chamber to cylinder walls. Features an elliptical design to ensure uniform bearing surface under heat expansion, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany. Specifications include a bore of 97.96 mm, piston size of 98.02 mm, displacement of 577 cm³, stroke of 76.40 mm, clearance of 0.06 mm, Wossner compression ratio of 11.00:1, OEM compression ratio of 10.00:1, dome volume of +8.20 cm³, and compression height of 25.00 mm. Cross-reference OEM part numbers for lock: CW22, pin: WP009, and ring set: 980XSY. Weight: 590g.
- SKU
- 56-W019.C.WO
- Brand
- Wossner
- Availability
- In Stock (4)
Fitments (16)
| Make | Model | Year |
|---|---|---|
| HUSQVARNA | TC 570 | 2001 |
| HUSQVARNA | TC 570 | 2002 |
| HUSQVARNA | TC 610 | 1999 |
| HUSQVARNA | TC 610 | 2000 |
| HUSQVARNA | TC 610 | 2001 |
| HUSQVARNA | TC 610 | 2002 |
| HUSQVARNA | TC 610 | 2003 |
| HUSQVARNA | TC 610 | 2004 |
| HUSQVARNA | TE 570 | 2001 |
| HUSQVARNA | TE 570 | 2002 |
| HUSQVARNA | TE 610 | 1999 |
| HUSQVARNA | TE 610 | 2000 |
| HUSQVARNA | TE 610 | 2001 |
| HUSQVARNA | TE 610 | 2002 |
| HUSQVARNA | TE 610 | 2003 |
| HUSQVARNA | TE 610 | 2004 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- Variant Id
- 254269
FULL DESCRIPTION
Wossner High Compression Piston Kit
Upgrade your engine's performance with this Wossner forged piston kit, engineered for superior strength and high compression. This kit is designed for optimal heat transfer from the combustion chamber to the cylinder walls. Its innovative elliptical design ensures a uniform bearing surface even under heat expansion, effectively reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany for exceptional quality.
Key Features
- Forged Construction: Provides enhanced durability and strength for demanding conditions.
- Optimized Heat Transfer: Improves thermal efficiency and overall engine performance.
- Elliptical Design: Prevents localized pressure buildup and guards against piston collapse under stress.
- High Compression: Designed to increase engine efficiency and power output.
Specifications
- Bore: 97.96 mm
- Piston Size: 98.02 mm
- Displacement: 577 cm³
- Stroke: 76.40 mm
- Clearance: 0.06 mm
- Wossner Compression Ratio: 11.00:1
- OEM Compression Ratio: 10.00:1
- Dome Volume: +8.20 cm³
- Compression Height: 25.00 mm
Component Details
- Lock: CW22
- Pin: WP009
- Ring Set: 980XSY
