PISTON KIT FC FE 501 601 95.00, WOSSNER 8537DC HUSABERG

Wossner 95.02mm Forged Piston Kit

This Wossner forged piston kit, with a bore size of 95.02mm (94.97mm) and an oversize of +0.02mm, is precision-engineered in Germany for superior strength and performance. Designed for efficient heat transfer to the cylinder walls, it ensures uniform expansion and reduces localized pressure for optimal combustion efficiency. The unique elliptical design effectively distributes thrust loads, preventing piston collapse and ensuring a uniform bearing surface.

Key Features:

• Wossner forged piston for exceptional strength and durability.
• Engineered for optimized heat transfer and improved combustion.
• Elliptical design for balanced thrust load distribution.
• Precision manufacturing to prevent piston collapse.
• Made in Germany to high-quality standards.

Specifications:

• Bore Size: 95.02mm (94.97mm)
• Oversize: +0.02mm
• Displacement: 501cc
• Stroke: 84.00mm
• Clearance: 0.05mm
• Compression Ratio: OEM (11.80:1)
• Dome Volume: -2.10cm³
• Compression Height: 23.00mm
• Lock Part Number: CW20
• Pin Part Number: WP073 (Note: DA-DC uses WP073, D300 uses WP038)
• Ring Set Part Number: 950XSY
