PISTON KIT 99-00 KX125 54.00 B, WOSSNER 8057DB KAWASAKI
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner piston kit with 54.00mm bore and 53.96mm actual piston size for 125cc engines. Features precision-forged construction in Germany for superior strength, heat transfer, and durability in two-stroke applications. The elliptical shape ensures even pressure distribution and prevents piston collapse. Specifications include a 54.50mm stroke, 0.05mm clearance, 2-stroke compression ratio, and 29.30mm compression height. Included components are Wossner piston PN# 8057DB, lock PN# CW15, pin PN# WP032, ring set PN# RSB5400, and rod PN# P2034. Weight is 186 grams.
- SKU
- 56-W741+00B.WO
- Brand
- Wossner
- Availability
- In Stock (1)
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 54.00mm
- Variant Id
- 257582
FULL DESCRIPTION
Wossner Piston Kit for Kawasaki KX125
Upgrade your high-performance two-stroke engine with this precision-engineered Wossner piston kit. Designed for durability and optimal power delivery, this kit features a forged construction for superior strength and heat transfer.
Key Features:
- Precision forged in Germany for exceptional quality and performance.
- Forged construction provides enhanced strength and wear resistance.
- Engineered for optimal heat transfer from the combustion chamber to cylinder walls.
- Features an elliptical shape to ensure even pressure distribution and prevent piston collapse under thermal expansion.
Specifications:
- Bore Size: 54.00 mm
- Actual Piston Size: 53.96 mm
- Displacement (cm³): 125
- Stroke (mm): 54.50
- Clearance (mm): 0.05
- Compression Height (mm): 29.30
- Compression Ratio: 2-stroke (compatible with Wossner and OEM)
Included Components:
- Piston: Wossner PN# 8057DB
- Lock: PN# CW15
- Pin: PN# WP032
- Ring Set: PN# RSB5400
- Rod: PN# P2034
