PISTON KIT 95-20 KX100 1-RING, WOSSNER 8254DA KAWASAKI MX 13001-0123, K1300-10123
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with 18+, T&Cs apply
Wossner Piston Kit 8254DA is a standard-size forged piston with a 52.50mm bore. Manufactured in Germany, this piston offers exceptional strength, optimal heat transfer, and load distribution. Its elliptical profile ensures even bearing surface contact during heat expansion, reducing localised pressure and the risk of piston collapse. Features include a forged piston design for durability and performance, an elliptical shape for balanced thrust load distribution, and maximised heat dissipation. Specifications: Bore: 52.50 mm, Actual Piston Diameter: 52.45 mm, Stroke: 45.80 mm, Displacement: 100 cm³, Clearance: 0.05 mm, Compression Height: 26.00 mm, Wossner Compression Ratio: 2-stroke, OEM Compression Ratio: 2-stroke. Cross-references: Wossner Piston: 8254DA, Lock: CW14, Pin: WP025, Ring Set: RSB5250, Rod: P2005, Internal Part No: 56-W651.A.WO, OEM: 13001-0123, 09104898, 651M05250, K1300-10123. Additional Cross References: PISTON-ENGINE: 13001-0759, RING-PISTON TOP: 13003-1274, PIN-PISTON: 13002-1018, RING-SNAP: 92033-0005.
- SKU
- 56-W651.A.WO
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (40)
| Make | Model | Year |
|---|---|---|
| KAWASAKI | KX 100 | 1989 |
| KAWASAKI | KX 100 | 1990 |
| KAWASAKI | KX 100 | 1991 |
| KAWASAKI | KX 100 | 1992 |
| KAWASAKI | KX 100 | 1993 |
| KAWASAKI | KX 100 | 1994 |
| KAWASAKI | KX 100 | 1995 |
| KAWASAKI | KX 100 | 1996 |
| KAWASAKI | KX 100 | 1997 |
| KAWASAKI | KX 100 | 1998 |
| KAWASAKI | KX 100 | 1999 |
| KAWASAKI | KX 100 | 2000 |
| KAWASAKI | KX 100 | 2001 |
| KAWASAKI | KX 100 | 2002 |
| KAWASAKI | KX 100 | 2003 |
| KAWASAKI | KX 100 | 2004 |
| KAWASAKI | KX 100 | 2005 |
| KAWASAKI | KX 100 | 2006 |
| KAWASAKI | KX 100 | 2007 |
| KAWASAKI | KX 100 | 2008 |
| KAWASAKI | KX 100 | 2009 |
| KAWASAKI | KX 100 | 2010 |
| KAWASAKI | KX 100 | 2011 |
| KAWASAKI | KX 100 | 2012 |
| KAWASAKI | KX 100 | 2013 |
| KAWASAKI | KX 100 | 2014 |
| KAWASAKI | KX 100 | 2015 |
| KAWASAKI | KX 100 | 2016 |
| KAWASAKI | KX 100 | 2017 |
| KAWASAKI | KX 100 | 2018 |
| KAWASAKI | KX 100 | 2019 |
| KAWASAKI | KX 100 | 2020 |
| KAWASAKI | KX 100 | 2021 |
| KAWASAKI | KX 112 100 | 2022 |
| KAWASAKI | KX 112 100 | 2023 |
| KAWASAKI | KX 112 100 | 2024 |
| KAWASAKI | KX 112 100 | 2025 |
| SUZUKI | RM 100 | 2003 |
| SUZUKI | RM 100 | 2004 |
| SUZUKI | RM 100 | 2005 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- Variant Id
- 257340
FULL DESCRIPTION
Wossner 8254DA Forged Piston Kit
Experience superior strength and performance with the Wossner 8254DA Forged Piston Kit. Engineered in Germany, this high-quality piston is designed for demanding off-road applications, offering optimal heat transfer and exceptional durability under extreme conditions. Its precision forged construction ensures reliability and longevity.
The innovative elliptical profile of this piston is a key feature, guaranteeing even bearing surface contact even as the piston expands with heat. This design effectively minimizes localized pressure points, significantly reducing the risk of piston collapse and ensuring consistent operation. Manufactured with German precision, this kit delivers outstanding performance and a perfect fit.
Key Features:
- Forged piston design for maximum strength and resilience.
- Elliptical shape promotes balanced thrust load distribution during thermal expansion.
- Engineered for maximized heat dissipation from the combustion chamber to the cylinder wall.
- Precision manufactured in Germany for unparalleled quality.
- Includes one ring for optimal performance.
Specifications:
- Bore: 52.50 mm
- Actual Piston Diameter: 52.45 mm
- Stroke: 45.80 mm
- Displacement: 100 cm³
- Clearance: 0.05 mm
- Compression Height: 26.00 mm
- Wossner Compression Ratio: 2-stroke
- OEM Compression Ratio: 2-stroke
Included Components:
- Wossner Piston: 8254DA
- Lock: CW14
- Pin: WP025
- Ring Set: RSB5250
Cross-Reference OEM Part Numbers:
- Wossner Piston: 8254DA
- OEM: 13001-0123, 09104898, 651M05250, K1300-10123
