PISTON KIT 92-98 YZ250 68.00 B, WOSSNER 8023DB YAMAHA KIT
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with 18+, T&Cs apply
Wossner forged piston kit with a 68.01mm bore (+0.01mm oversize). This piston kit is designed for high performance and longevity, featuring an elliptical shape to enhance load distribution and thermal expansion tolerance, reducing localised pressure points and preventing structural failure. Manufactured in Germany, it ensures efficient combustion heat transfer to cylinder walls for stable engine operation. Specifications include an actual diameter of 67.95mm, compression height of 36.00mm, stroke of 68.00mm, displacement of 246 cm³, piston clearance of 0.06mm, and a 2-stroke compression ratio. Cross-reference OEM part numbers include Piston Kit Part No: 8023DB, Lock: CW18, Pin: WP033, Ring Set: RSB6800 x2, and Rod: P2029.
- SKU
- 56-W677.B.WO
- Brand
- Wossner
- Availability
- In Stock (2)
Fitments (23)
| Make | Model | Year |
|---|---|---|
| YAMAHA | WR 250 | 1988 |
| YAMAHA | WR 250 | 1989 |
| YAMAHA | WR 250 | 1990 |
| YAMAHA | WR 250 | 1991 |
| YAMAHA | WR 250 | 1992 |
| YAMAHA | WR 250 | 1993 |
| YAMAHA | WR 250 | 1994 |
| YAMAHA | WR 250 | 1995 |
| YAMAHA | WR 250 | 1996 |
| YAMAHA | WR 250 | 1997 |
| YAMAHA | WR 250 | 1998 |
| YAMAHA | WR 250 | 1999 |
| YAMAHA | YZ 250 | 1988 |
| YAMAHA | YZ 250 | 1989 |
| YAMAHA | YZ 250 | 1990 |
| YAMAHA | YZ 250 | 1991 |
| YAMAHA | YZ 250 | 1992 |
| YAMAHA | YZ 250 | 1993 |
| YAMAHA | YZ 250 | 1994 |
| YAMAHA | YZ 250 | 1995 |
| YAMAHA | YZ 250 | 1996 |
| YAMAHA | YZ 250 | 1997 |
| YAMAHA | YZ 250 | 1998 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 68.00mm
- Variant Id
- 257452
FULL DESCRIPTION
Wossner Forged Piston Kit - High Performance and Durability
Experience enhanced performance and longevity with this Wossner forged piston kit. Precision engineered in Germany, this kit is designed for high-strength applications, offering superior durability for your engine.
Key Features:
- Forged Piston Construction: Provides exceptional strength and resistance to wear for demanding use.
- Elliptical Profile Design: This advanced design improves load distribution and thermal expansion tolerance, reducing localized pressure points and minimizing the risk of structural failure.
- Optimized Heat Transfer: Facilitates efficient combustion heat transfer to cylinder walls, ensuring stable engine operation and consistent performance.
- Precision Engineering: Manufactured in Germany to exacting standards, guaranteeing quality and reliability.
- Reduced Thrust Load: The elliptical shape helps minimize thrust load concentration, preventing piston collapse and extending component life.
Specifications:
- Bore Size: 68.01mm (+0.01mm oversize)
- Actual Diameter: 67.95mm
- Compression Height: 36.00mm
- Stroke: 68.00mm
- Displacement: 246 cm³
- Piston Clearance: 0.06mm
- Compression Ratio: 2-stroke (compatible with Wossner and OEM specifications)
Included Components:
- Piston Kit Part No: 8023DB
- Lock: CW18
- Pin: WP033
- Ring Set: RSB6800 (x2)
- Rod: P2029
