PISTON KIT 88-89 CR125 55.00, WOSSNER 8125D100 HONDA MX
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with 18+, T&Cs apply
The Wossner 8125D100 piston kit features a forged construction for exceptional strength and reliability, optimized for heat dissipation from the combustion chamber to the cylinder wall. Its elliptical profile minimizes localized stress and prevents piston collapse, manufactured in Germany to precise performance standards. This kit is designed for a 55.00 mm bore with an actual bore diameter of 54.94 mm, a 54.00 mm stroke, and 125 cm³ displacement. Specifications include 0.06 mm clearance, 2-stroke compression ratio (Wossner and OEM), and 28.00 mm compression height. Components included are lock CW15, pin WP032, ring set RSB5500, and rod P2009. This is a Wossner part number 8125D100, with cross-reference part number 56-W564+P4.WO.
- SKU
- 56-W564+P4.WO
- Brand
- Wossner
- Availability
- In Stock (1)
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 55.0mm
- Variant Id
- 256887
FULL DESCRIPTION
Wossner Piston Kit for Honda CR125
This Wossner piston kit is engineered for high-performance applications. Manufactured in Germany, it features a forged construction for exceptional strength and reliability. The piston's elliptical shape is meticulously designed to distribute loads evenly under thermal expansion, which helps prevent damage and ensures longevity. This kit is designed to provide optimal heat transfer from the combustion chamber to the cylinder wall, contributing to improved performance.
Key Features
- Forged piston construction for superior strength and durability.
- Optimized heat dissipation for efficient cooling.
- Elliptical profile to minimise stress and prevent piston collapse.
- Precision manufactured in Germany to exacting standards.
- Includes all necessary components for installation.
Specifications
- Bore Size: 55.00 mm
- Actual Bore Diameter: 54.94 mm
- Stroke: 54.00 mm
- Displacement: 125 cm³
- Clearance: 0.06 mm
- Compression Ratio: 2-stroke (Wossner and OEM)
- Compression Height: 28.00 mm
Wossner Components Included
- Piston Kit Part Number: 8125D100
- Lock Ring: CW15
- Piston Pin: WP032
- Ring Set: RSB5500
- Rod: P2009
