PISTON KIT 88-07 YFS200 67.50, WOSSNER 8101D150 YAMAHA ATV
Wossner 8101D150 forged piston kit features a 67.50mm bore (+1.50mm oversize). This piston is designed for optimal combustion efficiency and structural integrity, with superior heat dissipation and load distribution. Its elliptical shape minimises localised pressure and the risk of piston collapse. Manufactured in Germany, it is forged for increased strength and reliability. Specifications include a bore size of 67.50 mm, actual bore diameter of 67.44 mm, stroke of 57.00 mm, displacement of 199 cm³, clearance of 0.06 mm, compression height of 29.90 mm, and a 2-stroke type compression ratio. Includes piston kit part number 8101D150, lock CW16, pin WP027, ring set RSB6750 (x2), and rod P2030.
- SKU
- 56-W573+150.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner 8101D150 Forged Piston Kit 67.50mm Bore (+1.50mm Oversize)
This Wossner 8101D150 forged piston kit is a high-quality replacement component designed for enhanced performance and durability. Engineered with precision in Germany, it features a 67.50mm (+1.50mm) oversize bore to maximize combustion efficiency and structural integrity. The piston's advanced elliptical design minimizes localized pressure and the risk of piston collapse, ensuring uniform bearing surface and thrust load distribution even under extreme thermal stress. This kit is built for superior heat dissipation and load distribution, making it an ideal choice for performance-oriented applications.
Key Features
- Forged construction for increased strength and reliability.
- Optimized for superior combustion chamber heat transfer.
- Elliptical design for uniform bearing surface and thrust load distribution.
- Reduces the risk of piston collapse under thermal stress.
- Precision manufactured in Germany for exceptional quality.
Specifications
- Bore Size: 67.50 mm
- Actual Bore Diameter: 67.44 mm
- Stroke: 57.00 mm
- Displacement: 199 cm³
- Clearance: 0.06 mm
- Compression Height: 29.90 mm
- Compression Ratio: 2-stroke type (Wossner and OEM)
Component Cross-References
- Piston Kit: 8101D150
- Lock: CW16
- Pin: WP027
- Ring Set: RSB6750 (x2)
- Rod: P2030
