PISTON KIT 88-04 KX500 86.00, WOSSNER 8228DA KAWASAKI MX 13001-1327

Wossner Forged Piston Kit 86mm Bore for Kawasaki KX500

This Wossner forged piston kit is engineered for exceptional durability and precision, specifically designed for the high-performance demands of the Kawasaki KX500. With a standard bore of 86mm, this piston is crafted to ensure efficient combustion and maintain structural integrity even under extreme thermal and mechanical stress. Its advanced elliptical design aids in the even distribution of thrust loads, significantly improving wear resistance and helping to prevent premature piston failure. Manufactured in Germany, this piston kit is optimized to meet the rigorous performance requirements of two-stroke engines.

Key Features

• Forged construction provides superior strength and durability for demanding riding conditions.
• Features an elliptical design for consistent expansion and optimal load distribution across the piston surface.
• Engineered for efficient heat transfer from the combustion chamber to the cylinder wall, promoting consistent performance.
• Manufactured in Germany, ensuring high standards of quality and precision.

Specifications

• Bore Size: 86.00 mm (actual diameter 85.93 mm)
• Stroke: 86.00 mm
• Display Volume: 500 cm³
• Compression Height: 37.50 mm
• Clearance: 0.07 mm
• Wossner Compression Ratio: 2-stroke
• OEM Compression Ratio: 2-stroke

Cross-Reference Information

• OEM Part Numbers: Kawasaki 13001-1327, Wiseco 575M08600, Other 09104889
• Wossner Part Numbers: Piston Kit 8228DA, Lock CW19, Pin WP019, Ring Set RSC8600 x2, Rod P2039
