PISTON KIT 87-88 RM250 67.00, WOSSNER 8157DA SUZUKI MX 12110-00B24-0F0
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with 18+, T&Cs apply
Wossner 67.00mm standard bore forged piston kit for the Suzuki RM250 1987-1988. Designed for two-stroke applications, this piston features a forged construction and an elliptical profile for enhanced thermal expansion control, strength, and even thrust load distribution. Manufactured in Germany, it promotes efficient heat transfer from the combustion chamber to the cylinder walls for reliable performance. Specifications include a bore of 67.00mm, actual diameter of 66.94mm, displacement of 246 cm³, stroke of 70.00mm, clearance of 0.06mm, compression height of 37.00mm, and a 2-stroke compression ratio. Includes piston kit part no. 56-W558+000.WO, Wossner piston kit no. 8157DA, lock CW18, pin WP033, ring set RSB6700, OEM reference 12110-00B24-0F0, and additional reference 558M06700.
- SKU
- 56-W558+000.WO
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (2)
| Make | Model | Year |
|---|---|---|
| SUZUKI | RM 250 | 1987 |
| SUZUKI | RM 250 | 1988 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 67mm
- Variant Id
- 256803
FULL DESCRIPTION
Wossner Forged Piston Kit for Suzuki RM250
This Wossner 67.00mm standard bore forged piston kit is engineered for high-performance two-stroke applications. Its advanced design ensures exceptional strength, controlled thermal expansion, and even thrust load distribution for reliable operation under demanding conditions.
Key Features:
- Forged Piston Construction: Enhances strength and reliability for extended engine life.
- Elliptical Design: Provides a uniform bearing surface, adapting effectively to heat expansion.
- Even Thrust Load Distribution: Minimizes localized stress, reducing the risk of piston failure.
- Efficient Heat Transfer: Promotes optimal heat dissipation from the combustion chamber to the cylinder walls.
- German Manufacturing: Built to exacting standards in Germany.
Specifications:
- Bore: 67.00mm
- Actual Diameter: 66.94mm
- Displacement: 246 cm³
- Stroke: 70.00mm
- Clearance: 0.06mm
- Compression Height: 37.00mm
- Compression Ratio: 2-stroke
Component Details:
- Wossner Piston Kit Number: 8157DA
- Lock: CW18
- Pin: WP033
- Ring Set: RSB6700
OEM Reference Cross-Reference:
- 12110-00B24-0F0
- 558M06700
