PISTON KIT 86-07 CR80 48.00, WOSSNER 8238D100 HONDA MX
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with 18+, T&Cs apply
The Wossner 8238D100 piston kit features an 80 cm³ displacement and a 70.80mm stroke. It has a 48mm bore with an actual size of 47.95mm and a 37.00mm compression height. The kit includes lock part number CW14, pin part number WP058, and ring set part number RSB4800. Manufactured in Germany, this forged piston is designed for efficient heat transfer from the combustion chamber to the cylinder walls. Its elliptical profile ensures consistent load distribution under heat expansion, reducing localised pressure points and minimising the risk of piston collapse. The clearance is 0.06mm. This is a 2-stroke piston.
- SKU
- 56-W643.P4.WO
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (39)
| Make | Model | Year |
|---|---|---|
| HONDA | CR 80 | 1986 |
| HONDA | CR 80 | 1987 |
| HONDA | CR 80 | 1988 |
| HONDA | CR 80 | 1989 |
| HONDA | CR 80 | 1990 |
| HONDA | CR 80 | 1991 |
| HONDA | CR 80 | 1992 |
| HONDA | CR 80 | 1993 |
| HONDA | CR 80 | 1994 |
| HONDA | CR 80 | 1995 |
| HONDA | CR 80 | 1996 |
| HONDA | CR 80 | 1997 |
| HONDA | CR 80 | 1998 |
| HONDA | CR 80 | 1999 |
| HONDA | CR 80 | 2000 |
| HONDA | CR 80 | 2001 |
| HONDA | CR 80 | 2002 |
| HONDA | CR 80R | 1986 |
| HONDA | CR 80R | 1987 |
| HONDA | CR 80R | 1988 |
| HONDA | CR 80R | 1989 |
| HONDA | CR 80R | 1990 |
| HONDA | CR 80R | 1991 |
| HONDA | CR 80R | 1992 |
| HONDA | CR 80R | 1993 |
| HONDA | CR 80R | 1994 |
| HONDA | CR 80R | 1995 |
| HONDA | CR 80R | 1996 |
| HONDA | CR 80R | 1997 |
| HONDA | CR 80R | 1998 |
| HONDA | CR 80R | 1999 |
| HONDA | CR 80R | 2000 |
| HONDA | CR 80R | 2001 |
| HONDA | CR 80R | 2002 |
| HONDA | CR 85 | 2003 |
| HONDA | CR 85 | 2004 |
| HONDA | CR 85 | 2005 |
| HONDA | CR 85 | 2006 |
| HONDA | CR 85 | 2007 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 48.00mm
- Variant Id
- 257249
FULL DESCRIPTION
Wossner 48mm Piston Kit for Honda CR80
Optimize your Honda CR80's performance with this high-quality Wossner forged piston kit. Engineered for superior strength and durability, this piston is designed to enhance combustion heat transfer to the cylinder walls, leading to more efficient operation. Its advanced elliptical design ensures a uniform bearing surface even during thermal expansion, effectively reducing localized pressure points and minimizing the risk of piston collapse.
Key Features:
- Forged construction for exceptional strength and longevity.
- Designed for efficient heat transfer from the combustion chamber to the cylinder walls.
- Elliptical profile promotes consistent load distribution under thermal expansion.
- Manufactured in Germany to exacting standards.
Specifications:
- Bore Size: 48mm (actual size 47.95mm)
- Lock Part Number: CW14
- Pin Part Number: WP058
- Ring Set Part Number: RSB4800
- Displacement: 80 cm³
- Stroke: 70.80mm
- Clearance: 0.06mm
- Compression Height: 37.00mm
