PISTON KIT 85-00 XR600R 97.00, FORGED WOSSNER 8574DB

Wossner 97.01mm Forged Piston Kit for Honda XR600R

Enhance the performance and durability of your motorcycle with the Wossner 97.01mm Forged Piston Kit. Engineered in Germany, this high-quality piston kit is designed for optimal combustion chamber heat transfer and uniform load distribution, significantly reducing localized pressure and preventing piston collapse under demanding conditions.

Key Features:

• Forged Construction: Provides superior strength and exceptional durability for long-lasting performance.
• Optimized Heat Transfer: Efficiently transfers heat to cylinder walls, promoting cooler operation.
• Elliptical Design: Ensures a uniform bearing surface even under heat expansion, maintaining consistent performance.
• Reduced Localized Pressure: Evenly distributes thrust loads, preventing stress concentration.
• Piston Collapse Prevention: Engineered to withstand high-stress conditions without failure.

Specifications:

• Bore Size: 97.01mm (Actual Size: 96.95mm)
• Wossner Part Number: 8574DB
• Lock Part Number: CW24
• Pin Part Number: WP057
• Ring Set Part Number: 970XSY
• Rod Part Number: P4028
• Displacement: 591 cm³
• Stroke: 80.00mm
• Clearance: 0.06mm
• Compression Ratio: 9.30:1
• OEM Compression Ratio: 9.00:1
• Dome Volume: -4.80 cm³
• Compression Height: 29.70mm
• Theoretical Weight: 348.00g
