PISTON KIT 80-82 CR80 49.50, WOSSNER 8277DA HONDA MX 13102-169-000
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner forged piston kit with bore size 49.50 mm and actual bore 49.45 mm. Features forged construction for enhanced durability and strength, optimized heat transfer for improved performance, and an elliptical design for uniform bearing surface and reduced wear. Designed for 2-stroke engines with a stroke of 41.40 mm and clearance of 0.05 mm. Compression height is 27.00 mm. Compression ratio is 2-stroke. Displacement is 79 cm³. Manufactured in Germany. Wossner Part No. 8277DA. Cross-references OEM part numbers 13102-169-000 and 450M05000. Includes lock P/N CW12, pin P/N WP091, and ring set P/N RSB4950 x 2.
- SKU
- 56-W450+P0.WO
- Brand
- Wossner
- Availability
- In Stock (1)
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 49.5mm
- Variant Id
- 255671
FULL DESCRIPTION
Wossner Forged Piston Kit for Honda CR80R
This high-performance forged piston kit from Wossner is engineered for Honda CR80R models manufactured between 1980 and 1982. Crafted with precision in Germany, this piston kit is designed to elevate the durability and efficiency of your motorcycle's engine.
Key Features:
- Forged Construction: Provides superior strength and resilience compared to cast pistons, ensuring long-lasting performance under demanding conditions.
- Optimized Heat Transfer: Enhanced heat dissipation properties contribute to improved engine efficiency and reliability.
- Elliptical Design: The unique elliptical shape promotes a uniform bearing surface, reducing localized stress and minimizing wear for extended piston life.
- 2-Stroke Engine Specific: Tailored for optimal performance in 2-stroke engine applications.
Technical Specifications:
- Bore Size: 49.50 mm
- Actual Bore: 49.45 mm
- Stroke: 41.40 mm
- Clearance: 0.05 mm
- Compression Height: 27.00 mm
- Compression Ratio: 2-stroke
- Displacement: 79 cm³
- Manufacturing Origin: Made in Germany
Component Part Numbers:
- Wossner Part Number: 8277DA
- Lock Ring Part Number: CW12
- Piston Pin Part Number: WP091
- Ring Set Part Number: RSB4950 (Quantity: 2)
Cross-Reference OEM Part Numbers:
- 13102-169-000
- 450M05000
