PISTON KIT 71-89 TS125 58.00, FORGED WOSSNER 8146D200
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner forged piston kit with 58.00mm bore and 57.94mm diameter. Manufactured in Germany, this piston offers superior strength and design for optimal heat transfer to cylinder walls. Its elliptical design provides a uniform bearing surface under heat expansion, reducing localized pressure and evenly distributing thrust loads to prevent piston collapse. Features include forged construction for superior strength, optimized heat transfer for efficient combustion, and an elliptical design for uniform load distribution. Specifications: Bore 58.00mm, Diameter 57.94mm, Display (cm³) 125, Stroke (mm) 50.00, Clearance (mm) 0.06, Wossner Compression Ratio 2-Stroke, OEM Compression Ratio 2-Stroke, Compression Height (mm) 29.00. Cross-reference OEM Part Numbers: Wossner Piston Suzuki TS125 (PN# 8146D200), Lock P/N: CW14, Pin P/N: WP025, Ring Set P/N: RSB5800 x 2.
- SKU
- 56-W257.200.WO
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (33)
| Make | Model | Year |
|---|---|---|
| SUZUKI | RV 125 | 1974 |
| SUZUKI | RV 125 | 1975 |
| SUZUKI | RV 125 | 1976 |
| SUZUKI | RV 125 | 1977 |
| SUZUKI | RV 125 | 1978 |
| SUZUKI | TS 125 | 1971 |
| SUZUKI | TS 125 | 1972 |
| SUZUKI | TS 125 | 1973 |
| SUZUKI | TS 125 | 1974 |
| SUZUKI | TS 125 | 1975 |
| SUZUKI | TS 125 | 1976 |
| SUZUKI | TS 125 | 1977 |
| SUZUKI | TS 125 | 1978 |
| SUZUKI | TS 125 | 1979 |
| SUZUKI | TS 125 | 1980 |
| SUZUKI | TS 125 | 1981 |
| SUZUKI | TS ER 125 | 1971 |
| SUZUKI | TS ER 125 | 1972 |
| SUZUKI | TS ER 125 | 1973 |
| SUZUKI | TS ER 125 | 1974 |
| SUZUKI | TS ER 125 | 1975 |
| SUZUKI | TS ER 125 | 1976 |
| SUZUKI | TS ER 125 | 1977 |
| SUZUKI | TS ER 125 | 1978 |
| SUZUKI | TS ER 125 | 1979 |
| SUZUKI | TS ER 125 | 1980 |
| SUZUKI | TS ER 125 | 1981 |
| SUZUKI | TS X 125 | 1984 |
| SUZUKI | TS X 125 | 1985 |
| SUZUKI | TS X 125 | 1986 |
| SUZUKI | TS X 125 | 1987 |
| SUZUKI | TS X 125 | 1988 |
| SUZUKI | TS X 125 | 1989 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 58mm
- Variant Id
- 255268
FULL DESCRIPTION
Wossner Forged Piston Kit 58.00mm
Upgrade your engine's performance with this Wossner forged piston kit. Engineered for superior strength and durability, this piston is designed to optimize heat transfer to the cylinder walls, ensuring efficient combustion and reliable operation.
The advanced elliptical design of this piston provides a uniform bearing surface even under extreme heat expansion. This intelligent design reduces localized pressure points and evenly distributes thrust loads, effectively preventing piston collapse and extending the life of your engine components.
Key Features:
- Forged construction for exceptional strength and longevity.
- Optimized for efficient heat transfer, leading to improved combustion.
- Elliptical design ensures uniform load distribution for reduced wear.
- Precision manufactured in Germany for guaranteed quality.
Specifications:
- Bore Diameter: 58.00mm
- Piston Diameter: 57.94mm
- Engine Displacement: 125cm³
- Stroke: 50.00mm
- Piston to Cylinder Clearance: 0.06mm
- Compression Height: 29.00mm
- Wossner Compression Ratio: 2-Stroke
- OEM Compression Ratio: 2-Stroke
Included Components:
- Wossner Piston (Part Number: 8146D200)
- Lock Ring (Part Number: CW14)
- Piston Pin (Part Number: WP025)
- Ring Set (Part Number: RSB5800) - Quantity: 2
