PISTON KIT 71-89 TS125 56.00, FORGED WOSSNER 8146DA 12110-28004

£131.94
1

Wossner forged piston kit 8146DA with a 56.00mm bore and 55.94mm diameter. Manufactured in Germany, this piston offers superior strength and design for optimal heat transfer. Its elliptical design provides a uniform bearing surface under heat expansion, reducing localized pressure and evenly distributing thrust loads to prevent piston collapse. Specifications include a 125cm³ displacement, 50.00mm stroke, 0.06mm clearance, 29.00mm compression height. This kit includes lock P/N CW14, pin P/N WP025, and two ring sets P/N RSB5600. OEM reference part number is 12110-28004.

Specifications
SKU
56-W257.000.WO
Brand
Wossner
Availability
In Stock (1)

Fitments (33)

MakeModelYear
SUZUKIRV 1251974
SUZUKIRV 1251975
SUZUKIRV 1251976
SUZUKIRV 1251977
SUZUKIRV 1251978
SUZUKITS 1251971
SUZUKITS 1251972
SUZUKITS 1251973
SUZUKITS 1251974
SUZUKITS 1251975
SUZUKITS 1251976
SUZUKITS 1251977
SUZUKITS 1251978
SUZUKITS 1251979
SUZUKITS 1251980
SUZUKITS 1251981
SUZUKITS ER 1251971
SUZUKITS ER 1251972
SUZUKITS ER 1251973
SUZUKITS ER 1251974
SUZUKITS ER 1251975
SUZUKITS ER 1251976
SUZUKITS ER 1251977
SUZUKITS ER 1251978
SUZUKITS ER 1251979
SUZUKITS ER 1251980
SUZUKITS ER 1251981
SUZUKITS X 1251984
SUZUKITS X 1251985
SUZUKITS X 1251986
SUZUKITS X 1251987
SUZUKITS X 1251988
SUZUKITS X 1251989
General Product Group
Engine
General Product Type
Pistons & Kits
General Size
56mm
Variant Id
255261
Shipping OptionsShown at checkout
14-Day ReturnsHassle-free
Easy CheckoutCard friendly
Product details

FULL DESCRIPTION

Wossner Forged Piston Kit for TS125 Series

This Wossner forged piston kit is engineered for enhanced performance and durability in your Suzuki TS125, RV125, TS125ER, and TS125X. Manufactured in Germany, Wossner pistons are renowned for their superior strength and advanced design, contributing to optimal heat transfer to the cylinder walls. The unique elliptical piston design ensures a consistent bearing surface even under extreme heat expansion. This design minimizes localized pressure points and evenly distributes thrust loads, effectively preventing piston collapse and promoting a longer lifespan for your engine.

Key Features:

  • Forged construction provides exceptional strength and resilience.
  • Engineered for optimized heat transfer, leading to efficient combustion.
  • Features an elliptical design that ensures uniform load distribution and reduces localized pressure.
  • Precision manufactured in Germany for high quality and reliability.

Specifications:

  • Bore: 56.00mm
  • Diameter: 55.94mm
  • Cubic Capacity: 125 cm³
  • Stroke: 50.00mm
  • Clearance: 0.06mm
  • Compression Height: 29.00mm

Included Components:

  • Piston: Wossner Piston Suzuki TS125 (Part Number 8146DA)
  • Lock Retainers: CW14
  • Wrist Pin: WP025
  • Ring Set: RSB5600 (Quantity 2)

Original Equipment Manufacturer (OEM) Cross-Reference:

  • 12110-28004
