PISTON KIT 1990 KX125 56.50, WOSSNER 8106D050 KAWASAKI MX
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner forged piston kit 56.50mm bore, +0.50mm oversize (actual 56.44mm). Designed for high-performance 2-stroke engines. Forged construction ensures durability, strength, and superior heat dissipation. Elliptical shape promotes even thrust load distribution during thermal expansion. Precision-made in Germany. Features forged piston construction for improved mechanical strength and wear resistance, optimised design for effective combustion heat transfer to cylinder walls, elliptical profile to reduce localised pressure and improve load distribution, built for 2-stroke engine applications, and manufactured in Germany. Specifications: Bore size 56.50mm, actual bore 56.44mm, compression height 29.50mm, clearance 0.06mm, stroke 50.60mm, displacement 125 cm3. Cross-reference OEM part numbers: Wossner Piston 8106D050, Ring Set RSB5650, Lock CW16, Pin WP036, Rod P2033.
- SKU
- 56-W589+050.WO
- Brand
- Wossner
- Availability
- In Stock (1)
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 56.50mm
- Variant Id
- 257012
FULL DESCRIPTION
Wossner Forged Piston Kit 56.50mm Bore
This Wossner forged piston kit is designed for high-performance 2-stroke engines. The forged construction ensures durability, strength, and superior heat dissipation. The piston's elliptical shape promotes even thrust load distribution during thermal expansion, reducing the risk of localized stress and piston failure. Precision-made in Germany.
Key Features
- Forged piston construction for improved mechanical strength and wear resistance
- Optimized design for effective combustion heat transfer to the cylinder walls
- Elliptical profile reduces localized pressure and improves load distribution
- Built for 2-stroke engine applications
- Manufactured in Germany
Specifications
- Bore Size: 56.50mm (+0.50 oversize)
- Actual Bore: 56.44mm
- Compression Height: 29.50mm
- Clearance: 0.06mm
- Stroke: 50.60mm
- Displacement: 125 cm³
- Wossner Compression Ratio: 2-stroke
- OEM Compression Ratio: 2-stroke
Wossner Part Number
8106D050
