PISTON KIT 1987 RM125 54.50, WOSSNER 8122D050 SUZUKI MX 12110-01B38-0F0

£112.58Only 1 left

4.4 Trustpilot 99.9% positive on eBay

Free UK delivery 2–4 business days

Spread the cost with Klarna 18+, T&Cs apply

1

This Wossner 54.50mm (+0.50 oversize) forged piston kit is designed for two-stroke engine performance. The piston features a forged design and elliptical profile to manage heat expansion and mechanical stress effectively. Manufactured in Germany, it ensures efficient heat transfer and even thrust load distribution to support engine durability under high operating conditions. This kit includes a forged piston, lock CW14, pin WP025, and two ring sets RSB5450. Specifications include a bore of 54.50mm, actual diameter of 54.44mm, displacement of 123 cm³, stroke of 70.00mm, clearance of 0.06mm, compression height of 37.00mm, and a 2-stroke compression ratio. The Wossner part number is 8122D050 and the OEM reference is 12110-01B38-0F0.

Specifications
SKU
56-W557+050_WO
Brand
Wossner
Availability
In Stock (1)
General Product Group
Engine
General Product Type
Pistons & Kits
General Size
54.5mm
Variant Id
256796
Delivery2–4 business days
14-Day ReturnsHassle-free
Easy CheckoutCard friendly
Product details

FULL DESCRIPTION

Wossner 54.50mm Forged Piston Kit for Two-Stroke Engines

Enhance your two-stroke engine's performance and durability with this Wossner forged piston kit. Engineered for precision and resilience, this kit is designed to meet the demanding conditions of high-performance riding.

Key Features

  • Forged Piston Construction: Offers superior strength and longevity compared to cast pistons, ensuring reliable performance under stress.
  • Elliptical Piston Profile: This advanced design adapts to thermal expansion, maintaining a uniform bearing surface and reducing mechanical stress for consistent operation.
  • Optimized Thrust Load Distribution: The piston's geometry ensures even distribution of forces, minimizing localized pressure points and preventing premature wear or failure.
  • Efficient Heat Transfer: Designed to effectively transfer combustion heat to the cylinder walls, aiding in temperature regulation and overall engine efficiency.
  • German Engineering: Manufactured in Germany, guaranteeing high standards of quality and precision in every component.

Technical Specifications

  • Bore Size: 54.50mm
  • Actual Piston Diameter: 54.44mm
  • Engine Displacement: 123 cm³
  • Stroke Length: 70.00mm
  • Recommended Piston Clearance: 0.06mm
  • Compression Height: 37.00mm
  • Compression Ratio Type: 2-stroke

Included Components

  • Piston Kit Part Number: 56-W557+
  • Wossner Piston Kit Number: 8122D050
  • Lock Ring: CW14
  • Piston Pin: WP025
  • Ring Set: RSB5450 (x2)

Cross-Reference OEM Part Number

12110-01B38-0F0
