PISTON KIT 15-16 CRF450R 96mm, WOSSNER 8919DA, 13110-MEN-A90
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner forged piston kit for Honda CRF450R 2015 onwards. Standard size replacement with 96mm bore size and 95.96mm actual piston size. Features forged construction for high durability and strength, elliptical design for uniform bearing surface, efficient heat transfer, and even thrust load distribution. Manufactured in Germany. Specifications include 449 cm³ displacement, 62.10mm stroke, 0.04mm piston clearance, OEM compression ratio of 12.50:1, -2.24 cm³ dome volume, 20.60mm compression height, 241.00g theoretical weight, CW19 circlip part number, WP028 pin part number, and 960ADS-2 ring set part number. Cross-reference OEM part numbers include 13110-MEN-A90 and 40089M09600.
- SKU
- 56-W927.A.WO
- Brand
- Wossner
- Availability
- In Stock (3)
Fitments (2)
| Make | Model | Year |
|---|---|---|
| HONDA | CRF 450R | 2015 |
| HONDA | CRF 450R | 2016 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 96.00mm
- Variant Id
- 258274
FULL DESCRIPTION
Wossner Forged Piston Kit - High Performance Replacement for Honda CRF450R
Upgrade your motorcycle's performance with this Wossner forged piston kit. Designed as a standard-size replacement for Honda CRF450R models, this kit is engineered for demanding four-stroke applications, providing superior durability and power.
Key Features:
- Forged Construction: Offers exceptional strength and resilience for high-performance riding and competitive use.
- Elliptical Design: Ensures a consistent bearing surface as the piston expands with heat, promoting longevity and efficiency.
- Optimized Heat Transfer: Facilitates effective heat dissipation from the combustion chamber to the cylinder walls, preventing overheating.
- Balanced Thrust Load: Distributes thrust loads evenly to prevent piston collapse, maintaining engine integrity under stress.
- German Engineering: Manufactured in Germany, guaranteeing precision and high-quality standards.
Specifications:
- Bore Size: 96.00mm
- Actual Piston Size: 95.96mm
- Displacement: 449 cm³
- Stroke: 62.10mm
- Piston Clearance: 0.04mm
- Compression Ratio (Wossner): OEM
- Compression Ratio (OEM): 12.50:1
- Dome Volume: -2.24 cm³
- Compression Height: 20.60mm
- Theoretical Weight: 241.00g
- Circlip Part Number: CW19
- Pin Part Number: WP028
- Ring Set Part Number: 960ADS-2
Cross-Reference OEM Part Numbers:
- 13110-MEN-A90
- 40089M09600
