PISTON KIT 13-18 SXF450 95mm WOSSNER 8873DA KTM, HIGH COMPRESSION 13.6:1 78930007300
Wossner forged high-compression piston kit with a 95mm bore size (94.95mm actual). This piston includes a two-ring configuration and an elliptical shape for even load distribution and enhanced heat dissipation. It features a high-compression dome with a compression ratio of 13.60:1 (OEM is 12.60:1). Specifications include a displacement of 449 cm³, 84.00 mm stroke, 0.05 mm clearance, +4.10 cm³ dome volume, and 22.80 mm compression height. Manufactured in Germany. Cross-reference OEM part numbers: 78930007300, 40117M09500, RC902M09500.
- SKU
- 56-W956.A.WO.HC
- Brand
- Wossner
- Availability
- Out of Stock
FULL DESCRIPTION
Wossner High Compression Piston Kit - 95mm Bore
This Wossner forged high-compression piston kit is designed to enhance the performance of competitive applications. It features a 95mm bore size (94.95mm actual) and a high-compression dome, significantly increasing the compression ratio for improved power output.
Key Features:
- Forged high-compression piston with a two-ring design for durability.
- Elliptical piston profile ensures even load distribution and manages thrust loads under heat expansion.
- Optimized for superior combustion heat transfer and long-lasting performance.
- Precision manufactured in Germany for exceptional quality.
Specifications:
- Bore Size: 95mm (actual 94.95mm)
- Displacement: 449 cm³
- Stroke: 84.00 mm
- Clearance: 0.05 mm
- Wossner Compression Ratio: 13.60:1
- OEM Compression Ratio: 12.60:1
- Dome Volume: +4.10 cm³
- Compression Height: 22.80 mm
Cross-Reference OEM Part Numbers:
- 78930007300
- 40117M09500
- RC902M09500
