PISTON KIT 13-14 CRF450 96.00, WOSSNER 8880DB
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Wossner forged piston kit 8880DB is a +0.01mm oversized piston with a 96.01mm nominal bore (measured at 95.97mm). This high-performance piston ensures superior strength, optimal heat transfer, and reliable engine fitment under demanding conditions. Features include forged piston construction for maximum strength and reliability, an elliptical design that distributes loads uniformly during thermal expansion, and engineered combustion heat transfer to the cylinder wall. It reduces localised pressure to prevent piston collapse. Made in Germany. Specifications: Bore 96.01mm (Measured 95.97mm), Display Volume 449 cm³, Stroke 62.10mm, Clearance 0.04mm, Compression Height 20.70mm, Wossner Compression Ratio OEM, OEM Compression Ratio 12.50:1, Dome Volume -2.60 cm³, Part No. 56-W916.B.WO (Wossner 8880DB), Ring Set 960ADS-2, Lock P/N CW19, Pin P/N WP028.
- SKU
- 56-W916.B.WO
- Brand
- Wossner
- Availability
- Out of Stock
Fitments (5)
| Make | Model | Year |
|---|---|---|
| HONDA | CRF 450R | 2013 |
| HONDA | CRF 450R | 2014 |
| HONDA | CRF 450R | 2015 |
| HONDA | CRF 450R | 2016 |
| HONDA | CRF 450X | 2005 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 96.00mm
- Variant Id
- 258226
FULL DESCRIPTION
Wossner 96.01mm Forged Piston Kit for CRF450R (2013-2014)
This Wossner forged piston kit is engineered for enhanced performance and durability in Honda CRF450R models. Featuring a +0.01mm oversized bore, this high-quality piston ensures a precise fit and optimal engine operation under demanding conditions. Manufactured in Germany, Wossner pistons are renowned for their superior strength and reliability.
Key Features:
- Forged piston construction for maximum strength and resistance to wear.
- Elliptical design promotes uniform load distribution during engine operation and thermal expansion.
- Optimized for effective combustion heat transfer from the piston crown to the cylinder wall.
- Designed to reduce localized pressure points, preventing piston collapse.
- Precision-made in Germany for guaranteed quality and performance.
Specifications:
- Bore Size: 96.01mm (actual measurement: 95.97mm)
- Nominal Bore: 96.00mm
- Display Volume: 449 cm³
- Stroke: 62.10mm
- Clearance: 0.04mm
- Compression Height: 20.70mm
- Wossner Compression Ratio: OEM
- OEM Compression Ratio: 12.50:1
- Dome Volume: -2.60 cm³
- Ring Set: 960ADS-2
- Lock P/N: CW19
- Pin P/N: WP028
