PISTON KIT 09-12 CRF450R 96 HC, WOSSNER 8768DA HONDA FORGED, 13110-MEN-A30
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with
18+, T&Cs apply
Wossner high-compression forged piston kit for Honda CRF450R 2009-2012. Features include forged construction for durability, an elliptical design for even thermal expansion, and a two-ring configuration. Made in Germany. Specifications: Bore size 96.00mm (actual 95.96mm), displacement 449 cm³, stroke 62.10mm, clearance 0.04mm, Wossner compression ratio 13.40:1, OEM compression ratio 12.00:1, dome volume -0.030 cm³, compression height 20.70mm. Cross-reference OEM part numbers: 13110-MEN-A30, 4979M09600.
- SKU
- 56-W4978.A.WO.H
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (8)
| Make | Model | Year |
|---|---|---|
| HONDA | CRF 450R | 2009 |
| HONDA | CRF 450R | 2010 |
| HONDA | CRF 450R | 2011 |
| HONDA | CRF 450R | 2012 |
| HONDA | CRF 450R | 2013 |
| HONDA | CRF 450R | 2014 |
| HONDA | CRF 450R | 2015 |
| HONDA | CRF 450R | 2016 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 96mm
- Variant Id
- 256524
FULL DESCRIPTION
Wossner High-Compression Forged Piston Kit for Honda CRF450R
Enhance the performance and durability of your Honda CRF450R with this Wossner high-compression forged piston kit. Engineered for superior strength and efficient heat transfer, this piston features an elliptical structure that ensures uniform bearing surfaces even under extreme thermal expansion. Designed for specific Honda CRF450R models, this kit includes a two-ring configuration for optimal performance.
Key Features:
- Forged Construction: Provides exceptional durability and strength for demanding off-road use.
- Elliptical Design: Promotes even thermal expansion and maintains consistent bearing surfaces.
- High-Compression Ratio: Increases engine power and responsiveness.
- Two-Ring Configuration: Designed for efficient sealing and performance.
- German Engineering: Manufactured in Germany, ensuring high quality and precision.
Specifications:
- Bore Size: 96.00mm (actual 95.96mm)
- Displacement: 449 cm³
- Stroke: 62.10mm
- Clearance: 0.04mm
- Wossner Compression Ratio: 13.40:1
- OEM Compression Ratio: 12.00:1
- Dome Volume: -0.030 cm³
- Compression Height: 20.70mm
Cross-Reference OEM Part Numbers:
- 13110-MEN-A30
- 4979M09600
