PISTON KIT 05-21 YZ125 54.00 C, WOSSNER 8160DC YAMAHA MX
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Spread the cost with 18+, T&Cs apply
Piston Kit 54.00MM Bore 53.97 Wossner 8160DC (+0.02). Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany. Part No. 56-W845.C.WO Lock P/N CW15 Pin P/N WP032 Ring Set P/N RSB5400 Rod P/N P2018 Display (cm3) 125 Hub stroke (mm) 54.50 Clearance (mm) 0.05 Wossner compression Ratio: 2 stroke OEM Compression ratio: 2 stroke Dome volume (cm3) Compression height (mm) 28.00 Theorectical weight (G) 182. Cross reference numbers ONLY. 1C3-11631-03-D0, 09104853, 845M05400 1C3-11631-03-D0 / 1C3-11631-03-C0 / 1C3-11631-03-A0 / 1C3-11631-03-B0 + 5NY-11611-00-00 + 1C3-11633-00-00 + 93450- 16068-00
- SKU
- 56-W845.C.WO
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (25)
| Make | Model | Year |
|---|---|---|
| FANTIC | XE 125 | 2021 |
| FANTIC | XE 125 | 2022 |
| FANTIC | XE 125 | 2023 |
| FANTIC | XX 125 | 2021 |
| YAMAHA | YZ 125 | 2004 |
| YAMAHA | YZ 125 | 2005 |
| YAMAHA | YZ 125 | 2006 |
| YAMAHA | YZ 125 | 2007 |
| YAMAHA | YZ 125 | 2008 |
| YAMAHA | YZ 125 | 2009 |
| YAMAHA | YZ 125 | 2010 |
| YAMAHA | YZ 125 | 2011 |
| YAMAHA | YZ 125 | 2012 |
| YAMAHA | YZ 125 | 2013 |
| YAMAHA | YZ 125 | 2014 |
| YAMAHA | YZ 125 | 2015 |
| YAMAHA | YZ 125 | 2016 |
| YAMAHA | YZ 125 | 2017 |
| YAMAHA | YZ 125 | 2018 |
| YAMAHA | YZ 125 | 2019 |
| YAMAHA | YZ 125 | 2020 |
| YAMAHA | YZ 125 | 2021 |
| YAMAHA | YZ 125X | 2020 |
| YAMAHA | YZ 125X | 2021 |
| YAMAHA | YZ 125X | 2022 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 54.00mm
- Variant Id
- 258021
FULL DESCRIPTION
Wossner Forged Piston Kit 54.00MM Bore
Experience superior strength and design with the Wossner forged piston kit. Engineered for optimal performance, this piston kit is crafted to provide the most efficient path for combustion chamber heat transfer to the cylinder walls. Its elliptical design ensures a uniform bearing surface even under extreme heat expansion, eliminating localized pressure and distributing thrust loads evenly to prevent piston collapse. Made in Germany, this high-quality piston kit is built to last.
Key Features:
- Wossner forged pistons offer enhanced strength and advanced design.
- Optimizes combustion chamber heat transfer to cylinder walls.
- Elliptical design for uniform bearing surface under heat expansion.
- Distributes thrust loads evenly, preventing piston collapse.
- Manufactured in Germany.
- Bore Size: 54.00MM
- Specified Clearance: 0.05mm
- Compression Height: 28.00mm
- Included Lock P/N: CW15
- Included Pin P/N: WP032
- Included Ring Set P/N: RSB5400
Cross Reference Numbers:
- 1C3-11631-03-D0
- 09104853
- 845M05400
