PISTON KIT 05-09 TM 450 F 95mm, FORGED WOSSNER 8714DC
Wossner forged piston kit with a 95mm bore and 95.02mm piston size, featuring forged construction for enhanced durability and optimized heat transfer for improved performance. The elliptical design prevents localized pressure and piston collapse, distributing thrust loads evenly. Manufactured in Germany, this kit maintains the OEM compression ratio of 11.90:1 and has a dome volume of -11.40 cm³. Specifications include a displacement of 144 cm³, stroke of 63.40 mm, clearance of 0.04 mm, and compression height of 25.50 mm. Cross-reference part numbers: Lock CW19, Pin WP037, Ring Set 950ADS. Weight 424g.
- SKU
- 56-W038.WO.C
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 95mm for TM 450 F
Experience enhanced strength and performance with this Wossner forged piston kit. Engineered for optimal heat transfer from the combustion chamber to the cylinder walls, this piston utilizes an advanced elliptical design to ensure a uniform bearing surface even under heat expansion. This design effectively reduces localized pressure and distributes thrust loads evenly, preventing piston collapse and promoting longevity.
Key Features:
- Forged construction for superior durability and strength.
- Optimized heat transfer for improved engine performance.
- Elliptical design to prevent localized pressure and potential piston collapse.
- Maintains OEM compression ratio for a direct fit replacement.
Specifications:
- Bore: 94.98 mm
- Piston Size: 95.02 mm
- Stroke: 63.40 mm
- Clearance: 0.04 mm
- Wossner Compression Ratio: OEM
- OEM Compression Ratio: 11.90:1
- Dome Volume: -11.40 cm³
- Compression Height: 25.50 mm
Included Components:
- Lock: CW19
- Pin: WP037
- Ring Set: 950ADS
