PISTON KIT 02-06 KTM450 HC 95, FORGED WOSSNER 8571DB
4.4 Trustpilot 99.9% positive on eBay
Free UK delivery 2ā4 business days
Spread the cost with 18+, T&Cs apply
Wossner 95.01mm high-compression forged piston kit with an elliptical design for uniform bearing surface, reducing localized pressure and distributing thrust loads evenly. Engineered for optimal heat transfer for efficient cooling. Manufactured in Germany for precision and reliability. Bore Size: 95.01mm. Actual Bore Diameter: 94.97mm. Displacement: 449 cm³. Stroke: 63.40mm. Clearance: 0.04mm. Wossner Compression Ratio: HC (High Compression). OEM Compression Ratio: 12.00:1. Dome Volume: +11.50 cm³. Compression Height: 21.60mm. Lock Part Number: CW20. Pin Part Number: WP079. Ring Set Part Number: 950ADS-2. Wossner Part No: 8571DB. Weight: 392g.
- SKU
- 56-W4806.B
- Brand
- Wossner
- Availability
- In Stock (1)
Fitments (16)
| Make | Model | Year | Notes |
|---|---|---|---|
| KTM | 450 SM R | 2004 | ā |
| KTM | 450 SM R | 2005 | ā |
| KTM | 450 SM R | 2006 | ā |
| KTM | 450 SM R | 2007 | ā |
| KTM | 450 SM-R | 2004 | ā |
| KTM | 450 SMR | 2005 | ā |
| KTM | 450 SMR | 2006 | ā |
| KTM | 450 SMR | 2007 | ā |
| KTM | 450 SX | 2003 | 1st Filter |
| KTM | 450 SX | 2004 | 1st Filter |
| KTM | 450 SX | 2005 | 1st Filter |
| KTM | 450 SX | 2006 | 1st Filter |
| KTM | 450 SXF | 2003 | 1st Filter (Long) |
| KTM | 450 SXF | 2004 | 1st Filter (Long) |
| KTM | 450 SXF | 2005 | 1st Filter (Long) |
| KTM | 450 SXF | 2006 | 1st Filter (Long) |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 95mm
- Variant Id
- 256133
FULL DESCRIPTION
Wossner 95.01mm High-Compression Forged Piston Kit
Upgrade your engine's performance with this Wossner high-compression forged piston kit. Engineered for precision and durability, this piston is designed to optimize engine power and efficiency. Its forged construction provides superior strength, ensuring longevity under demanding conditions. The advanced design focuses on efficient heat transfer, contributing to effective cooling of the combustion chamber. A key feature is its elliptical profile, which promotes a uniform bearing surface, effectively reducing localized pressure and distributing thrust loads evenly. This design helps prevent piston collapse and maintains optimal engine operation.
Key Features:
- High-compression design for enhanced engine performance.
- Forged construction offers superior strength and durability.
- Optimized for heat transfer, aiding in efficient combustion chamber cooling.
- Elliptical design aids in preventing piston collapse and ensures even load distribution.
- Manufactured in Germany, adhering to high-quality standards.
Specifications:
- Bore Size: 95.01mm
- Actual Bore Diameter: 94.97mm
- Displacement: 449 cm³
- Stroke: 63.40mm
- Clearance: 0.04mm
- Compression Ratio: HC (High Compression)
- Dome Volume: +11.50 cm³
- Compression Height: 21.60mm
- Lock Part Number: CW20
- Pin Part Number: WP079
- Ring Set Part Number: 950ADS-2
Cross-Reference Information:
- Wossner Part Number: 8571DB
