PISTON KIT 01-14 KX85 52.50, WOSSNER 8102D400 KAWASAKI MX
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
Wossner forged piston kit with 52.50mm bore and 52.45mm piston diameter. Features forged aluminium construction for durability, excellent heat dissipation, and structural integrity for 2-stroke engines. Designed for efficient heat transfer, elliptical shape for consistent bearing surface during thermal expansion, and even thrust load distribution. Manufactured in Germany. Specifications: Bore 52.50mm, Piston Diameter 52.45mm, Display (cm³) 85, Stroke (mm) 45.80, Clearance (mm) 0.05, Compression Height (mm) 26.00, Wossner Compression Ratio 2-stroke, OEM Compression Ratio 2-stroke. Included components: Lock CW14, Pin WP058, Ring Set RSB5250, Rod P2005. Part Number: 56-W782_400.WO.
- SKU
- 56-W782_400.WO
- Brand
- Wossner
- Availability
- Out of Stock
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 52.50mm
- Variant Id
- 257755
FULL DESCRIPTION
Wossner Piston Kit - High Performance Forged Aluminium
This Wossner piston kit features a 52.50mm bore and a 52.45mm actual piston diameter, engineered for demanding 2-stroke applications. Constructed from forged aluminium, this piston offers superior durability, excellent heat dissipation, and robust structural integrity to withstand high-performance conditions.
Key Features:
- Forged Aluminium Construction: Ensures exceptional strength and long-lasting durability.
- Efficient Heat Transfer: Facilitates effective heat management by transferring heat from the combustion chamber to the cylinder walls.
- Elliptical Design: Maintains a consistent bearing surface throughout thermal expansion cycles.
- Even Thrust Load Distribution: Prevents localized pressure buildup and the risk of piston collapse, promoting consistent performance.
- Precision Manufacturing: Proudly manufactured in Germany for quality and reliability.
Specifications:
- Bore: 52.50mm
- Piston Diameter: 52.45mm
- Displacement: 85 cm³
- Stroke: 45.80mm
- Clearance: 0.05mm
- Compression Height: 26.00mm
- Wossner Compression Ratio: 2-stroke
- OEM Compression Ratio: 2-stroke
Included Components:
- Lock: CW14
- Pin: WP058
- Ring Set: RSB5250
- Rod: P2005
