PISTON KIT 00-20 KX65 44.50 D, WOSSNER 8196DD KAWASAKI MX
4.1 Trustpilot 99.9% positive on eBay
Free UK delivery 2–4 business days
This Wossner forged piston kit features a 44.53mm bore size with an actual piston size of 44.48mm and a clearance of 0.05mm. It is designed for two-stroke engines with a 65cm³ displacement and a 41.60mm stroke. The piston has a compression height of 23.60mm and a compression ratio suitable for both Wossner and OEM applications. Precision-forged in Germany, this piston kit offers superior durability, wear resistance, and reliable thermal performance. Its elliptical design ensures a uniform bearing surface, reducing stress and preventing piston collapse. Included components are piston (Wossner PN# 8196DD), lock (PN# CW12), pin (PN# WP091), ring set (PN# RSB4450), and rod (PN# P2001). The kit weighs 120 grams.
- SKU
- 56-W752.D.WO
- Brand
- Wossner
- Availability
- Out of Stock
Fitments (39)
| Make | Model | Year |
|---|---|---|
| KAWASAKI | KX 65 | 2000 |
| KAWASAKI | KX 65 | 2001 |
| KAWASAKI | KX 65 | 2002 |
| KAWASAKI | KX 65 | 2003 |
| KAWASAKI | KX 65 | 2004 |
| KAWASAKI | KX 65 | 2005 |
| KAWASAKI | KX 65 | 2006 |
| KAWASAKI | KX 65 | 2007 |
| KAWASAKI | KX 65 | 2008 |
| KAWASAKI | KX 65 | 2009 |
| KAWASAKI | KX 65 | 2010 |
| KAWASAKI | KX 65 | 2011 |
| KAWASAKI | KX 65 | 2012 |
| KAWASAKI | KX 65 | 2013 |
| KAWASAKI | KX 65 | 2014 |
| KAWASAKI | KX 65 | 2015 |
| KAWASAKI | KX 65 | 2016 |
| KAWASAKI | KX 65 | 2017 |
| KAWASAKI | KX 65 | 2018 |
| KAWASAKI | KX 65 | 2019 |
| KAWASAKI | KX 65 | 2020 |
| KAWASAKI | KX 65 | 2021 |
| KAWASAKI | KX 65 | 2022 |
| KAWASAKI | KX 65 | 2023 |
| KAWASAKI | KX 65 | 2024 |
| KAWASAKI | KX 65 | 2025 |
| SUZUKI | RM 65 | 2000 |
| SUZUKI | RM 65 | 2001 |
| SUZUKI | RM 65 | 2002 |
| SUZUKI | RM 65 | 2003 |
| SUZUKI | RM 65 | 2004 |
| SUZUKI | RM 65 | 2005 |
| SUZUKI | RM 65 | 2006 |
| SUZUKI | RM 65 | 2007 |
| SUZUKI | RM 65 | 2008 |
| SUZUKI | RM 65 | 2009 |
| SUZUKI | RM 65 | 2010 |
| SUZUKI | RM 65 | 2011 |
| SUZUKI | RM 65 | 2012 |
- General Product Group
- Engine
- General Product Type
- Pistons & Kits
- General Size
- 44.50mm
- Variant Id
- 257659
FULL DESCRIPTION
Wossner 44.53mm Piston Kit
This high-performance Wossner piston kit is engineered for demanding two-stroke engine rebuilds and performance applications. Precision forged in Germany, this piston offers exceptional strength, reliable thermal management, and an optimal fit to ensure maximum engine efficiency and longevity.
Key Features
- Forged Piston Construction: Provides superior durability and enhanced resistance to wear for long-lasting performance.
- Optimized Heat Transfer: Designed to efficiently transfer heat from the combustion chamber to the cylinder walls, promoting stable operating temperatures.
- Elliptical Piston Design: Ensures a uniform bearing surface, reducing localized stress and preventing piston collapse for consistent operation.
- German Engineering: Meticulously manufactured in Germany for precise fitment and high-quality, reliable performance.
Specifications
- Bore Size: 44.53 mm
- Actual Piston Size: 44.48 mm
- Engine Displacement: 65 cm³
- Stroke: 41.60 mm
- Clearance: 0.05 mm
- Compression Ratio: Compatible with two-stroke Wossner and OEM specifications
- Compression Height: 23.60 mm
Included Components
- Wossner Piston (Part # 8196DD)
- Lock Ring (Part # CW12)
- Piston Pin (Part # WP091)
- Ring Set (Part # RSB4450)
- Wossner Rod (Part # P2001)
