HOSE REAR BRAKE RED +2, TRX450R 2004-2009 HONDA FIR, KIT DONE
M10 20° banjo quick-disconnect dry break fitting for brake and clutch systems. Features a quick-disconnect mechanism that prevents fluid loss and air ingress during system maintenance. Compatible with JIC 600-03 (3/8 x 24) and AN3 fittings. Designed for use with Factory Image Racing swivel hose fittings. Requires 25mm long banjo bolts for installation. Specifications include M10 size, 20° angle, AN3 (JIC 600-03, 3/8 x 24) thread, and a total length of 75mm ±1mm. Compatible brake hose end is BUILDALINE 02-622 (3/8 UNF female concave).
- SKU
- 02-019.RD+2
- Brand
- Factory Image Racing
- Availability
- In Stock (61)
FULL DESCRIPTION
Factory Image Racing M10 20 Degree Banjo Quick Disconnect Fitting
The M10 20° banjo quick-disconnect dry break fitting is engineered for precise functionality in brake and clutch systems. This innovative fitting allows for the removal of components without any loss of fluid or the introduction of air into the system, ensuring a clean and efficient maintenance process.
Designed to seamlessly interface with AN3 (JIC 600-03, 3/8×24) fittings, this quick-disconnect fitting requires specific banjo bolts for proper installation. Its purpose-built design makes it ideal for motorcycle brake systems.
Key Features
- Quick-Disconnect Mechanism: Effectively prevents fluid loss and avoids air ingress during system maintenance, maintaining brake system integrity.
- AN3 (JIC 600-03) Compatibility: Works with standard AN3 (JIC 600-03, 3/8 x 24) fittings, offering broad compatibility.
- Swivel Hose Fitting Ready: Intended for use with Factory Image Racing swivel hose fittings for a complete and integrated solution.
- Specific Banjo Bolt Requirement: Installation requires 25mm long banjo bolts.
Specifications
- Size: M10
- Angle: 20°
- Thread: AN3 (JIC 600-03, 3/8 x 24)
- Total Length: 75mm ±1mm
- Compatible Brake Hose End: BUILDALINE 02-622 (3/8 UNF female concave)
