BUSH / CAP SWINGARM 17x27x8.5mm CAP SWING ARM PIVOT 11012-1790 EACH
4.1 Trustpilot 99.9% positive on eBay
UK delivery £4.99, free over £60 2–4 business days
Spread the cost with
18+, T&Cs apply
Bush/Cap for Swingarm Roller Pin. Type: Stepped bush with seal groove. Dimensions: Outer diameter 26.98 mm, overall width 8.50 mm. Internal bore: Primary inside diameter 22.00 mm, secondary inside diameter 17.07 mm, step depth 6.85 mm. Seal groove width 1.90 mm, depth 1.10 mm. The bush has a stepped internal bore with a 22.00 mm section stepping down to 17.07 mm. The step is 6.85 mm deep from one face. A seal groove is machined on the outer surface.
- SKU
- 74-415
- Brand
- Clearance Items
- Availability
- In Stock (916)
- General Product Group
- General Bearings & Seals
- General Product Type
- Oil Seal
- Variant Id
- 265427
FULL DESCRIPTION
Swingarm Pivot Bush with Seal Groove
This stepped bush is designed for use within a swingarm roller pin assembly. It features a specific stepped internal bore and a groove machined into its outer surface, likely intended to accommodate a seal for dust and moisture protection.
Key Features:
- Type: Stepped bush with seal groove
- Outer Diameter: 26.98 mm
- Overall Width: 8.50 mm
- Internal Bore (Stepped): 22.00 mm transitioning to 17.07 mm
- Step Depth: 6.85 mm
- Seal Groove Width: 1.90 mm
- Seal Groove Depth: 1.10 mm
