PISTON KIT 88-89 CR125 56.00, WOSSNER 8125D200 HONDA MX
The Wossner 8125D200 piston kit features a forged piston for maximum durability and excellent heat dissipation, manufactured in Germany. Its elliptical design ensures even distribution of thrust loads during thermal expansion, reducing the risk of piston collapse. This kit includes all critical components for installation, with a bore size of 56.00 mm, actual bore diameter of 55.94 mm, stroke of 54.00 mm, display displacement of 125 cm³, clearance of 0.06 mm, and compression height of 28.00 mm. The compression ratio is 2-stroke. Cross-reference part numbers include Piston Kit 8125D200, Lock CW15, Pin WP032, Ring Set RSB5600, and Rod P2009. The Wossner part number is 56-W564+P8.WO.
- SKU
- 56-W564+P8.WO
- Brand
- Wossner
- Availability
- Out of Stock
FULL DESCRIPTION
Wossner 56.00mm Piston Kit for Honda CR125
Upgrade your Honda CR125's performance with the Wossner 8125D200 Piston Kit. Engineered for durability and optimal power output, this kit is designed for 1988 and 1989 models and features a 56.00 mm bore for a +2.00 mm oversize application.
Key Features:
- Forged piston construction ensures maximum strength and longevity, even under demanding riding conditions.
- Manufactured in Germany, utilizing precision engineering for superior quality and performance.
- Advanced elliptical design effectively distributes thrust loads during thermal expansion, preventing localized pressure points and reducing the risk of piston collapse.
- Optimized for excellent heat dissipation, transferring combustion heat efficiently to the cylinder walls.
- Includes all essential components for a complete and reliable installation.
Specifications:
- Bore Size: 56.00 mm
- Actual Bore Diameter: 55.94 mm
- Stroke: 54.00 mm
- Display Displacement: 125 cm³
- Clearance: 0.06 mm
- Compression Ratio: 2-stroke (Wossner and OEM)
- Compression Height: 28.00 mm
Kit Components:
- Piston Kit: 8125D200
- Lock: CW15
- Pin: WP032
- Ring Set: RSB5600
